 Posted: Sep 06, 2014 17:25 Post subject: First attempt |
|
|
I decided to post this photo because of the rare character of the 3 conjoined quartz crystals. The shot was made using a Zeiss Stemi 2000 binocular microscope with a total magnification of 80X – the height of the picture is approx. 1.5 mm.
| Mineral: | Quartz |
| Locality: | | Chinook Ridge, Alberta, Canada |  |
|
| Dimensions: | 1.3 mm x 0.9 mm x 0.8 mm |
| Description: |
I know, the picture is not perfect – I just tried my best but you can see crystallographic face and edges. The 2 smaller crystals are terminated, at one end in trigonal prisms. The larger one has the terminations removed. And now the surprise – This specimen is from a lower Cretaceous Conglomerate of the Cadomin Formation in the Deep Basin Zone of the Western Canadian Sedimentary Basin. The over 1 mm size of the larger crystal suggests that at the time of crystallization there was an open space sufficient for this specimen to grow. Small drusy quartz crystals are common in large pores in sedimentary rocks (both clastic and carbonates) as well as in association of different clay minerals making up the filling of veins and fractures. The specimen on the right represents one of the sides of the “void” and there are still several drusy quartz crystals attached. Drusy quartz crystals are rare in the sedimentary domain and a three crystal aggregate of over 1 mm in length is even scarcer Thanks for your attention an understanding for the quality of the photo. Adrian Pripoae.
PS. I still have the specimens, so any advice regarding photo techniques that might increase quality are welcomed. |
|
| Viewed: |
12431 Time(s) |
|
|
|
| Back to top |
|
 |
Adrian Pripoae
Joined: 30 May 2014
Posts: 38
Location: Calgary
|
| Posted: Oct 23, 2014 13:25 Post subject: Re: First attempt |
|
|
A second try: Picture represents the Cretaceous Bluesky Formation sandstone, made of endogenous quartz fragments and chert (chalcedony) fragments bounded together by a siliceous cement partially recrystallized. The black zones are bitumen filling up the interstitial pores.
| Mineral: | Quartz, Chert (Chalcedony) Kaolinite (?) |
| Locality: | | Kaybob area, Fox Creek, Alberta, Canada | |
|
| Dimensions: | FOV 3.5 mm; 5 x magnification (Zeiss Stemi 2000) |
| Description: |
| Manual Focus; stacked with Helicon Focus 6Canon Rebel 3Ti. |
|
| Viewed: |
12028 Time(s) |
|
|
|
